Product Description: Square Cone Mixer - Efficient and Contained Blending with Vacuum Loading and Automated Discharge

Our Square Cone Mixer is designed for the homogeneous mixing of particles, granules, and powders in pharmaceutical, chemical, and food industries. It offers large batch mixing capabilities, reliable force application, and stable operation.

Purpose:

• Specifically engineered for mixing particles, granules, and powders in solid dosage manufacturing.
• Ideal for large batch mixing requirements.
• Suitable for pharmaceutical, chemical, and food industries.

Principle of Operation:

The Square Cone Mixer comprises a machine base, driving system, control system, and mixing bin. To operate:

1. Load materials into the mixing bin using a vacuum loading system for closed material transfer.
2. Secure the bin lid and set the mixing time and speed via the control system.
3. Initiate the mixing process.
4. Upon completion, the machine automatically stops, and the mixed materials are ready for discharge.
5. Discharge the mixed materials using an automated pneumatic cylinder对接料斗 for contained material transfer.

Key Features and Benefits:

• Vacuum Loading System: Ensures closed and contamination-free material loading.
• Automated Pneumatic Discharge: Provides contained and efficient material discharge via cylinder对接料斗.
• Large Batch Capacity: Ideal for high-volume production.
• 30° Rotating Angle: Enhances mixing efficiency through tumbling and tangential movement.
• GMP Compliance: Smooth surfaces, no dead corners, and no exposed screws.
• Anti-Misoperation Discharge Valve: Ensures production safety.
• Homogeneous Mixing: Achieves uniform blending of various materials.
• Stable Operation: Reliable performance for continuous production.
• User-Friendly Control System: Simplified operation and programming.
• Optimized Production Process: Streamlines material handling and improves efficiency.
